Assignment 3- Documentation

-
Introduction I drew inspiration from IKEA's Assembly and documentations. The documentation includes a progress of modelling 3 architectural precedents through different fabrication techniques.  Yim Hoi Fung z5042677 The full 103 pages documentation (Assignment 3 - Documentation) can be viewed in: https://issuu.com/ivan_yim1996/docs/assignment_3_a4_size_1 or you can download the pdf file in  Dropbox link:  https://www.dropbox.com/s/bg5wfqixla1vc6r/assignment%203%20-%20Documentation.pdf?dl=0 Google Drive backup link: https://drive.google.com/file/d/1s0O8rY57AlxP0iOGWx79XZmJRpKx_-_n/view?usp=sharing Documentation videos Model 1 - Bus Stop Krumpach Documentation: Process of learning soldering Model 2 - House OM Documentation: Process of laser-cutting the detailed facade mold Documentation: 1st and 2nd hydrostone test models Documentation: Hydrostone base casting Documentation: Casting and Demolding
Post a Comment
Read more

Assignment 2 The Fabrications

-
1. Bus Stop Krumpach - Sou Fujimoto 1:25 model Description: This model demonstrates a range of fabrication techniques to show the beauty of structure and the human interaction. The colour of timber and the copper metal rods match with each other and create a sense of abstractness and cozy atmosphere, which in contrast perfectly with the white cold scaled people model.   Material & Fabrication Techniques: Metalworking - Cut 60 pieces of long copper coating rods and 25 pieces of short copper coating rods for soldering after. Metalworking - Drill holes into the MPH timber block Soldering - Solder rods together with the short rods, with the media- "Baker Soldering Fluid". Woodworking - Trim and cut the MPH hardwood for the base by thicknesser and bandsaw Woodworking - Sanding the base surface with sand paper Woodworking - Polishing the base with orange oil Laser-cutting - Cutting Bamboo stairs and 3mm white acrylic 1:25 scaled models
Post a Comment
Read more

Assignment 1- Project Matrix (z5042677)

-
PDF download: https://drive.google.com/file/d/1_LssVNFVLcofozcZjs9JfT8VYpu1B_3G/view?usp=sharing
